RIDGID Tools RIDGID SeeSnake 85′ NanoReel N85S Reel 40008

Ridgid

SeeSnake nanoReel Industrial Video Inspection System

The nanoReel system opens up new possibilities in long run small diameter inspection needs. Applications where only bore scopes could reach can now be inspected using the nanoReel system. Boiler tubes; supply lines; sprinkler systems; and a wide array of specialty applications can be inspected using the nanoReel system.

1 (25 mm) capacity up to 85′ (25 m). Passes 90 bends in most 1 3/16 (30 mm) lines.

FEATURES:

• Small diameter and tight turn radius camera allows lines up to 85′ (25 m) to be inspected with tight turns in 1 (25 mm) lines.
• Lightweight and compact unit allows for easy transport and efficient storage.
• Interchangeable drums let you change out the inner drum depending on the application.
• Ideal for inspections with tight turns such as toilet traps and P-traps.

INCLUDES:

• Sonde in Camera Head

SPECIFICATIONS:

Camera Head	0.62 (15.5 mm)
Cable Length	85′ (25 m)
Cable Diameter	0.25 (6.3 mm)
Line Capacity	to 2″ (20 – 50 mm)
Weight	9.5 lbs. (4;1 kg)
Size	Length 13.25″ (33.7 cm); Width 6.6″ (16.8 cm); Height 17.5″ (44.5 cm)
Resolution	656 x 492
Ball Guide	2 Included
Sonde	512 Hz
Counter	Not Available

“
